125-150kg/H PP Packing Strap Extruder Production Line with automatic winder and double embossing

SHENZHEN JIATUO PLASTIC MACHINERY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

125-150kg/H PP Packing Strap Extruder Production Line with automatic winder and double embossing

Brand Name : JIATUO CHINA

Model Number : JTPP-90

Certification : IS CEO

Place of Origin : CHINA

MOQ : 1 SET

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 30-40days

Packaging Details : plastic film

Strap Color : Single/Multi-Color

Strap Speed : >250m/min

Strap Core Diameter : 406*150mm / 200*180mm

Strap Thickness : 0.4-1.2mm

Strap Tension : Adjustable

Strap Width : 5-19mm

Power Supply : 380V/220V

Exchange Filter : Fully Automatic

Screw Size : Single and Double screw

Production Capacity : 2.8T-12T/24hours

Contact Now

125-150kg/H PP Packing Strap Extruder Production Line with automatic winder and double embossing

Parameter of PP 2 belts extrusion line
Power 30-35KW Daily Capacity 125-150KG/H
Screw Diameter 90mm Plastic Processed PP
Screw Material 38CrMoALA Warranty one year
Voltage 380V/220V Dimension(L*W*H) 28m*2m*4m
Host Heating Power 12KW Oven Heating Power 8KW
Winding speed 260m/min Weight 3T

Process flow of PP packing belt production line

Feeding → stirring → pre-drying → melting and measuring extrusion → embryo (belt embryo) cooling and forming → oven preheating → primary stretching → secondary stretching → single / double embossning → Setting oven part → cooling → Automatic winder


We can printing the information on strap, if need it should be add printing machine before embossing machine

125-150kg/H PP Packing Strap Extruder Production Line with automatic winder and double embossing

Advantages of PP strip making machine

1. Flexible Extrusion Options: Special twin-screw or single-screw extrusion technology is available to meet specific customer requirements.

2. Material Compatibility: Capable of processing 100% recycled PP/PET bottle flakes or pellets.

3. Precision & Automation: Ensures uniform plasticization and stable extrusion with full-line PLC automatic control.

4. Customizable Coating: Coating materials can be tailored to enhance strap functionality. For example, cotton packing straps can be optimized for higher breaking strength and improved weld joint strength.

5. Advanced Filtration: Features a dual-piston melt filter with air venting and back-flushing capabilities.

Applications of PP strapping

Polypropylene Strapping is used for automatic strapping machine, semi-automatic strapping machine, and manual strapping machine. It is suitable for packing light weighted cartons or pallets weighing several kilograms to several hundred kilograms.

1. Standard PP Strapping: Suitable for light to medium-duty applications.

2. Reinforced PP Strapping: Contains additional materials for higher tensile strength.

3. UV-Resistant PP Strapping: Designed for outdoor use and prolonged exposure to sunlight.

125-150kg/H PP Packing Strap Extruder Production Line with automatic winder and double embossing

FAQ

Q1:What about the payment terms?
A1:Always 30% down payment as deposit,70% balance pay before shipping.

Q2:What about the payment way?
A2:TT,L/C at sight or MIC trade assurance.

Q3:If you will send engineer coming to our factory to install and test the machines?
A3:Yes,Every set of machine we will send professional engineer to your factory and help installation and test the machines for you.

Q4:If you have CE,SGS,ISO certificate?
A4:Yes,except these,if you also need other certificates,we also can help to apply.
